N Female to N Female Adaptor 18 GHz

Name: N Female to N Female Adaptor 18 GHz
SKU: 4729
Availability: InStock

Original price was: ₹3,328.00.Current price is: ₹2,924.00.

A N Female to N Female Adapter for extending N-Type cable runs or changing genders. It operates up to 18 GHz.

Product successfully added to the Quote List

Category: Adaptor Tags: n female to n female adaptor, N(F) TO N(F) ADAPTOR 18GHZ

Description

This N-Type female to N-Type female adapter is a fundamental component for extending the length of an N-Type cable or for converting an N-Type male connector to a N-Type female. It is rated for frequencies up to 18 GHz, making it suitable for a variety of high-power, high-frequency applications. The simple, compact design ensures a reliable and low-loss connection for signal continuity.

Additional information

Brand	RF CONNECTOR HOUSE
Body	Brass SS
Center Conductor	Phosphor Copper
Frequency Range	DC-18GHz
VSWR	1.5
Impedance	50?
Insertiona Loss	=0.10 dB
Insulator	PTFE Teflon
Durability	Mating Cycles =538
