SMA Female to SMA Female Bulkhead Adapter, 18 GHz

Name: SMA Female to SMA Female Bulkhead Adapter, 18 GHz
SKU: 4832
Availability: InStock

Original price was: ₹2,752.00.Current price is: ₹2,448.00.

A SMA Female to SMA Female Bulkhead Adapter for passing a signal through a panel. It operates up to 18 GHz and provides a secure, inline connection.

Product successfully added to the Quote List

Category: Adaptor Tags: Sma female to sma female bh adaptor, SMA(F) TO SMA(F) BH ADAPTOR 18GHZ

Description

This SMA female to SMA female bulkhead adapter is designed to provide a reliable, inline connection for passing a signal through a panel or chassis. The bulkhead design secures the adapter in place, preventing rotation and strain on the connection. Rated for frequencies up to 18 GHz, this adapter is commonly used in test equipment, video systems, and communication setups to create a durable and easily accessible external connection point.

Additional information

Brand	RF CONNECTOR HOUSE
Body	Brass SS
Center Conductor	Phosphor Copper
Frequency Range	DC-18GHz
VSWR	1.5
Impedance	50?
Insertiona Loss	=0.10 dB
Insulator	PTFE Teflon
Durability	Mating Cycles =571
